    Pipe Split Frame Tube Cutting And Chamfering Machine Clamshell Cold Cutting

    Ask Lasest Price
    Brand Name : Wellnit
    Model Number : OCH-1230
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 300set /month
    Delivery Time : with 7 days
    • Product Details
    • Company Profile

    Pipe Split Frame Tube Cutting And Chamfering Machine Clamshell Cold Cutting

    Pipe Split Frame Tube cutting and chamfering machine Clamshell Cold Cutting Portable Light


    Metal Square Round Tube Cutting Beveling Machine Rectangular Pipe Cutting and Beveling is a professional cutting machine develop by wellnit.This Cutting machine is cost less and easy for move.Much suitable for some small and medium company.

    Characteristic:

    • Cold Cutting and Beveling improves safety
    • Cutting and Beveling simultaneous
    • Split Frame: easy mounted on pipeline
    • Tools feed automatically
    • Fast, Precision, On-site Beveling
    • Minimal Axial and Radial clearance
    • Light weight and compact design
    • Easy set-up & Operation
    • Electric or Pneumatic or Hydraulic driven
    • Machining heavy-wall pipe from 3/4” up to 56”

    Applications:

    • Oil & Gas
    • Power Plant
    • Chemical Plant
    • Nuclear Power
    • Process Plant & Fabrication
    • Ship Building & Repair

    Specifications:

    • Drive Options: Pneumatic, Hydraulic, and Electric
    • Air requirement: 1500L-3000L Per minute 0.6/0.7Mpa
    • Hydraulic requirement: 2-60L per minute 12.5Mpa
    • Electric requirement:220-240V 1PH 50/60HZ
    • Feed mode: Star wheel, automatically
    • Feed rate: Fixed 0.08mm per circle
    • Packaging: Plywood case

    Machine Operation Types:


    Penumatic,Hydraulic power pack,CNC


    Tech date sheet:

    OD-Mounted Hydraulie Type :

    ModelWorking Range (ID-OD)InchWall ThicknessRotation Speed
    OCE-89Φ25-893/4''-3''≤35100r/min
    OCE-159Φ50-1592''-5''≤7096r/min
    OCE-168Φ50-1682''-6''≤7090r/min
    OCE-230Φ80-2303''-8''≤7085r/min
    OCE-275Φ125-2755''-10''≤7080r/min
    OCE-305Φ150-3056''-10''≤7073r/min
    OCE-325Φ168-3256''-12''≤7070r/min
    OCE-377Φ219-3778''-14''≤7062r/min
    OCE-426Φ273-42610''-16''≤7058r/min
    OCE-457Φ300-45712''-18''≤7055r/min
    OCE-508Φ355-50814''-20'≤7052r/min
    OCE-560Φ400-56016''-22''≤7052r/min
    OCE-610Φ457-61018''-24''≤7050r/min
    OCE-630Φ480-63020''-24''≤7050r/min
    OCE-660Φ508-66020''-26''≤7050r/min
    OCE-715Φ560-71522''-28''≤7048r/min
    OCE-762Φ600-76224''-30''≤7048r/min
    OCE-830Φ660-81326''-32''≤7045r/min
    OCE-914Φ762-91430''-36''≤7041r/min
    OCE-1066Φ914-106636''-42'≤7032r/min
    OCE-1230Φ1066-123042''-48''≤7030r/min
    OCE-1430Φ1230-143048''-56''≤7028r/min

    Machine on site:

    Packaging & Shipping

    Packaging: Standard machine will be ready and stabled in a wooden case.

    Shipping: Able to support with any shipping method as per customer 's requirements.

    Tube Duburring Machine for SS CS tube cutting and duburring


    COMPANY INTRODUCTION:


    Zhejiang Wellnit Mechanical Technology Co.,Ltd (Original:Wenzhou Huakai Co.,Ltd)is a professional manufacture and exporter that is concerned with the design,development and production of pipe cutting and beveling machine,portable plate beveling machine.

    The products include :

    • O.D. mounted light & heavy-duty pipe cutting and beveling machine,
    • I.D. mounted pipe beveling machine,
    • portable plate beveling machine.
    • flange facing machines.

    we have recieved ISO9001:2008,CE certificates etc.

    We are dedicate to continuing the spirit of innovation , manufacturing excellence, enthusiastic work force and the superb after sale service ,we are confident our future will be more and more successful.

    To be honest, pioneer and enterprising, seek for truth and innovation" is our credo.

    And "Your satisfaction is our great success"


    Order Guide:


    Before you place order to us, please let us know the following information:

    • Choose the right Model

    • Confirm your electric power supply ( Voltage, frequency and phase)

    • Confirm the beveling angel required

    • Confirm the welding joint required (U, V, Double V or Compound preparation)

    • Advise your pipe material ( Carbon steel, stainless steel or others)

    • Other special demands about machine

    • The spare parts needed

    • If the pipe wall thickness more than 30mm, inform us in advance (Important)
