    12r/Min Electric Pipe Cutting And Beveling Machine OCE-377

    High Efficient OCE-377 Pipe Cutting And Beveling Machine

    Main performance

    This machine adopts AC 220v high-performance motor as power, the motor frequency is 50HZ, the allowable current is 6A,

    and the motor power is 1.5-2KW. This machine is a portable external installation cutting and beveling machine,

    which has the characteristics of easy operation and small radial clearance.

    Machine Specification:

    ModelOCE-377
    Voltage220V
    Frequency50/60 Hz
    Power1800W
    Working Range(O.D)8”-14”

    Wall Thickness

    (Standard)

    Greater than 6mm

    Less than 30mm

    Rotation Speed12r/min
    Machine BodySteel
    DrivenElectric
    Net Weight73KGS
    Gross Weight110KGS

    Machine Packing List

    NameUnitQty
    MachineSet1
    Cutting ToolPcs2
    Beveling Tool (30degree)Pcs1
    Beveling Tool (37.5degree)Pcs1
    Allen WrenchSet1
    Sprinkling CanPcs1
    Oil GunPcs1
    Rubber HammerPcs1
    Square WrenchSet1
    AngleRulerPcs1
    Instruction manualPcs

    1


    Machine Feature:

    1. Cold cutting ,won’t influence the material of pipe.
    2. Can cutting and beveling at same time.
    3. Can separate to two half, suitable for pipe when two end can’t open.
    4. The tool not only can process carbon steel , stainless steel and alloy pipe.
    5. Bevel Type: “v” ;“U” ; “J” ; compound bevel ; counter boring etc.

    12r/Min Electric Pipe Cutting And Beveling Machine OCE-37712r/Min Electric Pipe Cutting And Beveling Machine OCE-377
