Portable Hydraulic Pipe Cutting And Beveling Machine Outter Mounted 1.5KW - 2KW

Production Description:

The series machine is ideal for all types of pipe cutting, beveling and end preparation.

The split frame design allows the machine to split in half at the frame and mount around

the OD of the in-line pipe or fittings for strong, stable clamping.

The equipment performs precision in-line cut or simultaneous cut/bevel, single point,

counterbore and flange facing operations, as well as weld end preparation on open ended pipe.

NC

Powerful drive, high efficiency

Low noise, stable performance

Ideal for heavy wall thickness & large size pipe

Electric requirement: 230V 1PH 50/60Hz

380V 3PH 50/60Hz

Power: 2.0KW or 3.0KW

Double motor for big model or heavy duty

16 models, working range for pipe OD 1"-48".

Non-standard model can be customized.

Out-mounted style, clamping by multipoint jaws.

Split frame technology, easy to install on the pipeline.

Cold cutting and beveling, don't influence the pipe's material.

Auto feed, cutting and beveling at the one time, cost effective.

Varity of beveling shape: "U", "V", "Y", J", double "V", compound bevels.

Stationary ring is steel; rotation ring is aluminum, and steel optional.

Electric, pneumatic, numerical control and hydraulic drive options are available.

Several different drive options are available to best position, the motor for a specific machining application.

It can be equipped a wide range of accessories to increase performance and expand

Capability

Pipe cut off

Pipe end beveling

Pipe facing

Cutting and beveling

Compound beveling

Counter boring

Flange facing

Grooving

Main Features:

 Zhejiang Wellnit Mechanical Technology Co.,Ltd

     Zhejiang Wellnit Mechanical Technology Co., Ltd. is located in Binhai Economic and Technological Development Zone, Wenzhou, Zhejiang Pro.China. It is a modern high-tech enterprise integrating R&D, manufacturing, sales and service.

The company specializes in the production of electric, pneumatic, hydraulic, CNC and explosion-proof groove cutting equipment, steel plate groove equipment.

  The company adheres to the principle of “taking market demand as the guide, customer satisfaction as the goal, pioneering and innovation as the driving force,honesty and trustworthiness as the principle, quality and cheap as the pursuit”, and has won the domestic market with excellent quality and perfect service. The international market is highly praised and trusted by users. The company's top ten series of dozens of products have been exported to more than 60 countries and regions in Europe, America, Middle East, Southeast Asia, etc., obtained CE certification, and passed the ISO9001 international management system certification.

      The company has dozens of senior engineers, professional engineers, senior management, sales and development talents, advanced testing equipment and perfect testing methods, providing the most powerful support for product development, innovation, production and marketing, advanced management concepts. And a perfect service system to inject new vitality into the company.

      Products are widely used in petroleum, power, steel, chemical, shipbuilding, natural gas, nuclear industry, pressure vessels and other industries, pipelines, power engineering installation and repair. For example, the West-East Gas Pipeline and the South-to-North Water Transfer have achieved significant production efficiency and economic benefits.
