Split Frame Electric AluminumClamshell Pipe Cutter 42 R/min
Rotation Speed
The series machine is ideal for all types of pipe cutting, beveling
and end preparation.
The split frame design allows the machine to split in half at the
frame and mount around
the OD of the in-line pipe or fittings for strong, stable clamping.
The equipment performs precision in-line
cut or simultaneous cut/bevel, single point, counterbore and flange
facing operations, as well as weld end
preparation on open ended pipe, Ranging from 3/4” to 56 inches
O.D.(DN20-1400), on most wall
thicknesses and material.
Adopt high strength & precision split frame ring structure,apply
for cut and bevel work for different
pipe,especially for batch working of cutting and beveling,get the
high efficiency.
Technical merits:
1:Lightweight and easily transportable machine (only 23 kg/50.7 lbs
or 26 kg/57.3 lbs) to provide flexibility
for on-site applications
2:Deformation-free clamping of thin-walled tubes
3:For cutting and beveling of tubes and elbows
4:Square, burr-free and deformation-free pipe end
5:Cold cutting process prevents corrosion
6:Orbital cutting process saves time
7:Multipoint clamping system of tubes
8:Fast adjustment of tube dimensions
(1) Easy to mount quickly,the swelling mechanism inserted into pipe
inner,can automatically locate and
center itself.
(2) The machine can not only process the U,V shape of pipe
beveling,and used fie carbon steels,stainless
steels and alloyed steel pipes,but also can treat the welded convex
flange and plain flange.
(3) Cold cutting process will not influence the quality of the
material of the pipe.
(4) Driven by Metabo motor, use more safety in the Inflammable and explosive site .
They are widely used in the fileds of repairing and installing the
pipe on site,such as the industry of the
petroleum,chemical, natural gas and so on.
Various of driven options: Pneumatic,Electric or Hydraulic.
1. Self-centering,no need adjust the concentricity &
perpendicularity manually Four clamp install
synchronously and high effect.
2. New clamping type,save the step of replace expending block.
3. Adopt new synchronous feeding mechanism, feeding uniformity,tool
bits has longer working life.
4. Easy set up ,operation and maintain.
5. Cutting & beveling finished at same time,high working effective.
6. Cold working,no spark,won’t make the material affected.
7. Perfect working precision,no burrs
8. Well-adapted,install split,you can make the speed adjust depend
on the working conditions.
Main Features:
1. Lower axial and radial clearance.
2. Cold cutting and beveling,No spark.
3. Easy set-up &Robust operation.
4. Process carbon steel ,stainless steel ,alloy etc with U,V,J
compound bevel.
5. Widely used in the fields of petroleum,chemical,natural gas,food
,boiler,medicine,power supply
construction and nuclear power.
| Model | working range(ID-OD) | wall thickness | rotation speed |
| OCE-89 | Φ25-89(1”-3”) | ≤30mm | 42r/min |
Note:Non-standard machine are available according to customers'
requirement.
They are widely used in the fileds of repairing and installing the
pipe on site,such as the industry of the
petroleum,chemical, natural gas and so on.
