    Simple Cold Working Plate Edge Milling Machine 0° - 60° Adjustable Slope Angle

    Ask Lasest Price
    Brand Name : Wellnit
    Model Number : PB-80
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30 sets a month
    Delivery Time : Within 7days after we received 100% payment
    • Product Details
    • Company Profile

    Simple Cold Working Plate Edge Milling Machine 0° - 60° Adjustable Slope Angle


    Simple Cold Working Plate Edge Milling Machine 0° -

    60° Adjustable Slope Angle


    Main performance of the product

    The PB-80 edge milling machine convenient movement and simple


    operation .

    The finish of the groove is as high as Ra3.2-6.3. It is suitable for small

    factoriess.

    The milling machine is equipped with commonly used CNC blades to make

    the customers use the cost more cheaply.

    Feature


    I Feed torque improve,performance stabily

    II Bevel angle can adjustable (Range 30°-60°)

    III Easy to operation

    IV Cold working,no spark

    V Bevel surface no oxide layer,don't need pickling,can weld directly.

    VI Equip with 4 ps CNC blades,High efficiency ,lower consume.

    Technical Parameter



    Model


    PB-80


    Slope Angle


    0°-60°(Adjustable)


    Power


    AC 380V 50Hz


    Clamp Thickness


    6-60mm


    Total


    4800W


    Clamp Width


    〉100mm


    Spindle Speed


    750-1050r/min (adjustadle)


    Process Length


    〉300mm


    Feed speed


    0~1500mm/min (adjustadle)


    Worktable Height


    820-860mm


    Milling Width


    0-70mm


    Net Weight


    220kg




    Single Milling

    Width




    15-20mm




    Processing Materials


    Carbon Steel


    Stainless Steel


    Aluminium Alloy , Etc


    Main product performance


    Pb-80 edge milling machine has the features of small size, light weight, convenient movement and simple


    operation, suitable for small factories. The speed of processing and milling machine is not inferior, in


    addition, this model of edge milling machine equipped with commonly used CNC blade, so that customers


    can use more affordable.

    Features: 1. Large adjustment range of groove Angle, arbitrary adjustment range from 0 to 60 degrees;

    2. The rear of the reducer is conducive to the processing of narrow plates and is more secure;

    3. The unique separate design of control box and electrical box makes the operation more secure;

    4. Use the milling cutter disk with dense teeth to cut the groove, making the single blade cutting easier;

    5. The surface finish of the processed groove reaches ra3.2-6.3 and completely meets the welding


    requirements of pressure vessel;

    6. Small size and light weight is a portable automatic walking and milling edge machine, as well as a


    portable groove machine;

    7. Cold cutting groove operation and no oxide layer on the surface of the groove.


    Details of Product


    Quality Simple Cold Working Plate Edge Milling Machine 0° - 60° Adjustable Slope Angle for sale
